1999-2006 (2007 Classic) GM 4WD 3/5 LOWERING KIT W/ BOLT ON C-NOTCH

$1,525.00 price excluding tax

-

IHC Suspension is excited to introduce the most complete 1999-2006 (2007 Classic) 4WD lowering kits in the market. IHC’s kit has all the features that most of our competitors just do not have.

Our key features that differentiate us from the competition:

  • Adjustable upper control arms for camber correction
  • IHC’s flip kit has the correct pinion angle built in so no need to use pinion shims.
  • Bolt on C-notch for your DIY. ¼” metal plate used. Grade 8 hardware!
  • All MADE IN USA!
  • Manufactured in TEXAS!
  • Lifetime warranty on all metal parts!

IHC’s 1999-2006 (2007 Classic) 4WD 3/5  lowering kit with bolt on C-notch consists of 2″ lowering spindles, 1″ lowering torsion key, and IHC’s adjustable upper control arms for camber correction. The rear consists of the flip kit, drop shocks, 1″ lift shackles, and bolt on under bed C-notch. All IHC Suspension parts are fiber laser cut, CNC bend, and robotically welded for precise quality.

SKU: IHC-GM9906CK-35 Categories: , , , , , , , ,
Additional Information
Weight 114 lbs
Kit Components

Kit Components

FRONT

  • 2″ Drop spindles
  • 1″ Drop Keys
  • Adjustable UCA

REAR

  • Flip kit
  • Drop shocks
  • 1″ lift shackles
  • Bolt on Under bed C notch
  • OPTIONAL Weld on c notch
PACKAGE WEIGHTS & DIMENSIONS

PACKAGE WEIGHTS & DIMENSIONS

IHC-GM9906UCA-ADJ + IHC-GM9906-TKEY

  • WEIGHT: 27 LBS.
  • DIMENSIONS: 14″X14″X10″

IHC-GM9906RK-5

  • WEIGHT: 43 LBS.
  • DIMENSIONS: 2″X12″X6″

IHC-GM9906-SPINDLES

  • WEIGHT: 45 LBS.
  • DIMENSIONS: 14″X14″X8″
INSTRUCTIONS

INSTRUCTIONS

  • Please read Instructions thoroughly and completely before beginning installation. Installation by a certified mechanic is recommended. IHC Suspension is NOT responsible for any damage or failure resulting from improper installation.
  • Estimated Installation Time: 4 Hours +/- (excluding alignment)

Rear Instructions (CLICK HERE)
